MWN Suction Rolls in Paper Manufacturing: Function and Benefits

What are Suction Rolls?
Suction rolls are rotating rolls with a perforated surface produced using the deep hole drilling process. Inside the roll, there is a vacuum that is transmitted to the surface through the suction holes. This creates a suction effect that can be used to dewater moist materials such as paper or cardboard and to remove them from one surface (e.g., wire/felt) and transfer them to another surface (e.g., felts). In the latter property, suction rolls can also be used in dry environments or non-paper-based applications (e.g., foil, technical nonwovens).
Do you still have questions about MWN suction rolls? Contact MWN here.

Function of Suction Rolls in Paper Manufacturing
In paper production, suction rolls are mainly used in the wire/press section. Here, the still-moist fiber web, which later becomes the paper, is transferred from the wire to the press felt using the suction roll - a process called couching.
The press felt then transports the fiber web through the so-called press nips. These are pairs of rolls that squeeze the web under high pressure and thus mechanically dewater it. Depending on the configuration of the press section, the paper web can reach a dry content of up to 55% here. In the press nips themselves, even higher values can be achieved, but the web is subject to certain rewetting effects, such as the capillary action in press and transport felts.
The press section with its suction rolls is usually the last station of the paper machine where mechanical dewatering takes place. In the subsequent drying section, the remaining moisture is removed from the paper web thermally through the heated surface of the drying cylinders.
Download the brochure about MWN's customized premium solutions here.

Advantages of MWN Suction Rolls
MWN Niefern is a leading manufacturer of suction rolls for the paper industry. MWN suction rolls are characterized by several special features that offer papermakers significant advantages:
• Uniform, stable vacuum distribution over the entire roll width for consistent web guidance and a high degree of running smoothness.
• Optimized suction hole geometry of the roll surface for efficient yet gentle dewatering, even at high production speeds.
• High performance and longevity due to robust construction and high-quality materials.
• Low-maintenance concept, specially developed for continuous hard use in paper machines.
• Customer-specific adaptations for optimal performance in every individual production environment.
MWN has already sold more than 800 suction rolls and more than 3,500 suction roll covers worldwide. Learn more about the high quality of our suction rolls here.

Conclusion: MWN Suction Rolls - The First Choice for Paper Manufacturers Who Value Productivity, Reliability, and Consistent Paper Quality
Suction rolls fulfill the important task of transferring the paper web from one wire or felt to the next in the wire/press section of paper machines and safely transporting it through press nips. In the process, they contribute significantly to mechanical dewatering and create the prerequisite for the final drying of the paper.
With their sophisticated design and customer-specific arrangement of suction zones and hole geometries, MWN suction rolls achieve particularly efficient and gentle web guidance. At the same time, they are impressive in their robustness, longevity, and low maintenance requirements. This makes them optimally tailored to the high demands of the paper industry.
For paper manufacturers who value productivity, reliability, and consistent paper quality, MWN suction rolls are the first choice. With their performance, they make a decisive contribution to securing the economic efficiency and competitiveness of paper mills.
